Mechanical

● Outline - 3U x 8HP front panel. Refer

to JE Outline Dwg #02638-000 or the

Mechanical Outline in this catalog

Complies with all current PICMG ®

CompactPCI PSU specifications

● Retaining Latches - Supplied

with a single Rittal #3686.135 Type

VI I (Telecom) Lower Latch. Other

manufacturers and types available.

Consult factory

● Guide Rails - Supplied with .260[6.61]

offset guide rails for use with Rittal

3687.832 (or equivalent) PSU guides

● Weight - Approx: 1.8 lbs / 1.06 kgs
